SRSide Roller Chain
ANSI｜Single Pitch｜Attachment
“SR” type roller chains are often used on accumulating conveyors. The side rollers may be staggered or parallel, with any spacing configuration. Roller materials are available in carbon steel or low friction plastic.
| SY Chain No. | Dimensions - mm | Average Chain Weight |
|||||||||||
| Pitch | Roller | Pin | Plate | Side Roller | |||||||||
| Width | Dia. | Dia. | Length | Height | Thick. | Dia. | Width | Pin-Length | |||||
| P | W | R | D | L1 | L2 | H | T | RS | ES | I1 | I2 | kg/m | |
| SY 40-1 SR | 12.70 | 7.95 | 7.92 | 3.96 | 8.3 | 9.4 | 11.7 | 1.5 | 15.88 | 7.6 | 17.3 | 19.1 | 0.86 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SY 50-1 SR | 15.88 | 9.53 | 10.16 | 5.08 | 10.2 | 11.8 | 14.6 | 2.0 | 19.05 | 9.2 | 21.4 | 23.1 | 1.40 |
| SY 60-1 SR | 19.05 | 12.70 | 11.91 | 5.95 | 12.8 | 14.1 | 17.5 | 2.4 | 22.23 | 12.5 | 27.9 | 30.0 | 1.93 |
| SY 80-1 SR | 25.40 | 15.88 | 15.88 | 7.93 | 16.4 | 19.1 | 23.4 | 3.2 | 28.58 | 15.6 | 34.8 | 37.8 | 3.30 |
| SY 100-1 SR | 31.75 | 19.05 | 19.05 | 9.53 | 19.7 | 23.3 | 29.3 | 4.0 | 39.67 | 18.5 | 41.9 | 45.5 | 3.57 |
SR type chain can be manufactured with plastic oversized carrier rollers.
