SRSide Roller Chain
ANSI｜Double Pitch｜Attachment
“SR” type roller chains are often used on accumulating conveyors. The side rollers may be staggered or parallel, with any spacing configuration. Roller materials are available in carbon steel or low friction plastic.
| SY Chain No. | Dimension - mm | Average Chain Weight |
||||||||||||
| Pitch | Roller | Pin | Plate | Side Roller | ||||||||||
| Width | Roller | Dia. | Dia. | Length | Height | Thickness | Dia. | Width | Pin-Length | |||||
| P | W | Type | R | D | L1 | L2 | H | T | RS | ES | I1 | I2 | kg/m | |
| SY C2040 SR | 25.40 | 7.95 | S | 7.92 | 3.96 | 8.3 | 10.0 | 11.4 | 1.5 | 15.88 | 7.6 | 17.3 | 19.1 | 0.61 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SY C2042 SR | R | 15.88 | 23.00 | 1.20 | ||||||||||
| SY C2050 SR | 31.75 | 9.53 | S | 10.16 | 5.08 | 10.2 | 12.0 | 15.0 | 2.0 | 19.05 | 9.2 | 21.4 | 23.1 | 1.01 |
| SY C2052 SR | R | 19.05 | 27.00 | 1.65 | ||||||||||
| SY C2060H SR | 38.10 | 12.70 | S | 11.91 | 5.95 | 14.4 | 16.6 | 17.0 | 3.2 | 22.23 | 12.5 | 29.5 | 31.6 | 1.65 |
| SY C2062H SR | R | 22.23 | 30.00 | 2.60 | ||||||||||
| SY C2080H SR | 50.80 | 15.88 | S | 15.88 | 7.93 | 17.8 | 21.0 | 22.6 | 4.0 | 28.58 | 15.6 | 36.5 | 39.5 | 2.74 |
| SY C2100H SR | 63.50 | 19.05 | R | 19.05 | 9.53 | 21.2 | 24.8 | 28.6 | 4.8 | 39.67 | 18.5 | 43.4 | 47.0 | 4.15 |
Roller Type "S" indicates a standard roller. Roller Type "R" indicates an oversized carrier roller. Roller Type "R" can be manufactured with plastic oversized carrier rollers.
