HPHollow Pin Chain
ANSI｜Single Pitch｜Miscellaneous
“HP” type chains are constructed with cold-forged solid bushings. This process assures that the inside diameter of the bushing’s hollow center is completely cylindrical all the way through. This unique hollow pin feature allows for easy insertion of cross rods without damaging the chain or rods.
| SY Chain No. | Dimension - mm | Average Tensile Strength |
Maximum Allowable Load |
Average Chain Weight |
||||||||||
| Pitch | Roller | Pin | Plate | |||||||||||
| Width | Dia. | Out-Dia. | In-Dia. | Length | Height | Thickness | ||||||||
| P | W | R | D | d | LR | LC | L1 | L2 | H | T | KN | KN | kg/m | |
| SY 40-1 HP | 12.70 | 7.95 | 7.92 | 5.63 | 4.03 | 16.7 | 17.6 | 8.4 | 9.2 | 12.0 | 1.5 | 12.70 | 1.77 | 0.58 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SY 50-1 HP | 15.875 | 9.53 | 10.16 | 7.09 | 5.13 | 20.1 | 21.5 | 10.1 | 11.4 | 15.0 | 2.0 | 19.60 | 3.14 | 0.97 |
| SY 60-1 HP | 19.05 | 12.70 | 11.91 | 8.29 | 6.04 | 26.0 | 27.2 | 13.0 | 14.2 | 18.1 | 2.4 | 28.40 | 4.22 | 1.46 |
| SY 80-1 HP | 25.40 | 15.88 | 15.88 | 11.34 | 8.08 | 32.4 | 34.3 | 16.2 | 18.1 | 24.1 | 3.2 | 51.00 | 7.65 | 2.47 |
HP type chains are a bushed chain which made without rollers. Offset links are not available.
