AP SLR-CSAqua-Proof Self Lube Roller Chain for Conveyor
ANSI|Single Pitch|Anti Corrosion|Lube Free
“AP SLR-CS” type roller chains are designed for both corrosion resistance and self lubrication. All components, except the oil-impregnated bushings, are treated with a dual layer coat treatment process before the chain is assembled to insure maximum protection. “AP SLR-CS” type roller chain is lubricated prior to delivery.
SY Chain No. | Dimension - mm | Average Tensile Strength |
Average Chain Weight |
||||||||||
Pitch | Roller | Pin | Plate | Trans. Pitch |
|||||||||
Width | Dia. | Dia. | Length | Height | Thickness | ||||||||
P | W | R | D | LR | LC | L1 | L2 | H | T | TP | KN | kg/m | |
SY 40-1 AP SLR-CS | 12.70 | 7.95 | 7.92 | 3.96 | 16.5 | 18.6 | 8.3 | 10.3 | 11.7 | 1.5 | - | 15.70 | 0.6 |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SY 40-2 AP SLR-CS | 31.1 | 33.2 | 15.6 | 17.6 | 14.4 | 31.40 | 1.1 | ||||||
SY 50-1 AP SLR-CS | 15.875 | 9.53 | 10.16 | 5.08 | 20.5 | 22.5 | 10.3 | 12.2 | 14.6 | 2.0 | - | 25.50 | 1.0 |
SY 50-2 AP SLR-CS | 39.1 | 40.9 | 19.6 | 21.3 | 18.1 | 51.00 | 1.9 | ||||||
SY 60-1 AP SLR-CS | 19.05 | 12.70 | 11.91 | 5.95 | 25.9 | 28.3 | 13.7 | 14.6 | 17.5 | 2.4 | - | 37.30 | 1.5 |
SY 60-2 AP SLR-CS | 49.3 | 51.8 | 24.7 | 27.1 | 22.8 | 74.60 | 2.8 | ||||||
SY 80-1 AP SLR-CS | 25.40 | 15.88 | 15.88 | 7.93 | 33.0 | 35.9 | 16.5 | 19.4 | 23.4 | 3.2 | - | 63.70 | 2.5 |
SY 80-2 AP SLR-CS | 62.2 | 65.5 | 31.1 | 34.4 | 29.3 | 127.00 | 4.9 | ||||||
SY 100-1 AP SLR-CS | 31.75 | 19.05 | 19.05 | 9.53 | 39.8 | 43.1 | 19.9 | 23.2 | 29.3 | 4.0 | - | 100.00 | 3.9 |
SY 100-2 AP SLR-CS | 75.4 | 79.1 | 37.7 | 41.4 | 35.8 | 200.00 | 7.6 | ||||||
SY 120-1 AP SLR-CS | 38.10 | 25.40 | 22.23 | 11.10 | 49.8 | 53.2 | 24.9 | 28.3 | 35.1 | 4.8 | - | 157.00 | 5.8 |
SY 120-2 AP SLR-CS | 95.4 | 99.6 | 47.7 | 51.9 | 45.4 | 314.00 | 11.1 |
AP SLR-CS type multiple strand chains are designed to be used with standard sprockets. Connecting links are "cotter" style for all sizes above 100 AP SLR-CS. Consult SUGIYAMA for offset links. Service life decreases dramatically if the lubricant in the oil-impregnated bushings is depleted. The lubrication in the oil-impregnated bushings will seep out rapidly when the operating temperature exceeds 70℃. A wet or dusty environment may lead to premature wearing. It is not recommended for applications which are exposed to chemicals or water, or associated with a shock load. Do not use Aqua-Proof chains in applications where chain may come in direct contact with food or where coating flakes or wear dust can contaminate food.
