LLLL Leaf Chain

BS｜Single Pitch｜Miscellaneous

“LL” type leaf chains consist of link plates of the same contour and thickness as the pin link plate of BS standard roller chain with the same pitch. The first number in the leaf chains identifies the chain pitch, and the last two numbers identify the chain’s lacing.

Drawingzoom
SY Chain No. Lacing Dimensions - mm Average
Tensile
Strength		 Average
Chain
Weight
Pitch Pin Plate Hole
Dia
Dia. Length Height Thickness
P D LR LC H T S KN kg/m
SY LL0822 2x2 12.70 4.45 7.6 9.4 10.9 1.25 4.46 17.80 0.31
SY LL0844 4x4 13.0 14.8 31.10 0.60
SY LL0866 6x6 18.4 20.2 44.50 0.89
SY LL1022 2x2 15.875 5.08 9.3 11.0 13.7 1.65 5.09 22.20 0.48
SY LL1044 4x4 16.1 18.0 44.50 0.94
SY LL1066 6x6 22.9 24.6 66.70 1.40
SY LL1222 2x2 19.05 5.72 10.7 13.0 16.1 1.8 5.73 28.90 0.63
SY LL1244 4x4 18.5 20.8 57.80 1.22
SY LL1266 6x6 25.9 28.3 86.70 1.82
SY LL1622 2x2 25.40 8.26 17.2 20.2 21.0 3.2 8.30 58.00 1.48
SY LL1644 4x4 30.2 33.2 116.00 2.90
SY LL1666 6x6 43.2 46.2 174.00 4.31
SY LL2022 2x2 31.75 10.16 20.1 23.8 26.4 3.5 10.21 95.00 2.17
SY LL2044 4x4 35.1 38.8 190.00 4.24
SY LL2066 6x6 50.1 53.8 285.00 6.30
SY LL2422 2x2 38.10 14.63 28.4 33.0 33.4 4.8 14.65 170.00 4.02
SY LL2444 4x4 49.4 54.0 340.00 7.79
SY LL2466 6x6 70.4 75.0 510.00 11.55
SY LL2822 2x2 44.45 15.88 34.0 39.2 37.0 6.3 15.92 200.00 5.42
SY LL2844 4x4 57.8 63.0 400.00 10.56
SY LL2866 6x6 86.0 91.2 600.00 15.71
SY LL3222 2x2 50.80 17.81 35.0 41.1 42.2 6.3 17.83 260.00 5.92
SY LL3244 4x4 58.6 64.6 520.00 11.50
SY LL3266 6x6 85.0 90.6 780.00 17.06
