FFlat Sidebar Roller Chain
ANSI｜Single Pitch｜Miscellaneous
“F”タイプは、プレートをくびれの無いフラット形状(小判形)にして、搬送物を直接載せる事を可能にした搬送用に適したチエンです。
| SY Chain No. | Dimension - mm | Average Tensile Strength |
Maximum Allowable Load |
Average Chain Weight |
|||||||||
| Pitch | Roller | Pin | Plate | ||||||||||
| Width | Dia. | Dia. | Length | Height | Thickness | ||||||||
| P | W | R | D | LR | LC | L1 | L2 | H | T | KN | KN | kg/m | |
| SY 35-1 F | 9.525 | 4.78 | 5.08 | 3.58 | 12.0 | 12.9 | 6.0 | 6.9 | 9.0 | 1.25 | 10.80 | 2.23 | 0.38 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SY 40-1 F | 12.70 | 7.95 | 7.92 | 3.96 | 16.6 | 17.7 | 8.3 | 9.4 | 11.7 | 1.5 | 19.10 | 4.17 | 0.67 |
| SY 50-1 F | 15.875 | 9.53 | 10.16 | 5.08 | 20.5 | 22.0 | 10.2 | 11.8 | 14.6 | 2.0 | 31.90 | 7.22 | 1.1 |
| SY 60-1 F | 19.05 | 12.70 | 11.91 | 5.95 | 25.7 | 26.9 | 12.8 | 14.1 | 17.5 | 2.4 | 43.10 | 10.70 | 1.63 |
| SY 80-1 F | 25.40 | 15.88 | 15.88 | 7.93 | 33.0 | 35.5 | 16.4 | 19.1 | 23.4 | 3.2 | 78.50 | 18.40 | 2.82 |
| SY 100-1 F | 31.75 | 19.05 | 19.05 | 9.53 | 39.6 | 43.0 | 19.7 | 23.3 | 29.3 | 4.0 | 118.00 | 28.30 | 4.37 |
| SY 120-1 F | 38.10 | 25.40 | 22.23 | 11.10 | 49.7 | 53.4 | 24.8 | 28.6 | 35.1 | 4.8 | 167.00 | 38.00 | 6.45 |
| SY 140-1 F | 44.45 | 25.40 | 25.40 | 12.70 | 54.0 | 58.3 | 27.0 | 31.3 | 40.9 | 5.6 | 216.00 | 50.30 | 8.29 |
| SY 160-1 F | 50.80 | 31.75 | 28.58 | 14.28 | 64.3 | 68.7 | 32.2 | 36.5 | 46.7 | 6.4 | 275.00 | 66.30 | 10.96 |
| SY 200-1 F | 63.50 | 38.10 | 39.67 | 19.83 | 78.5 | 87.0 | 39.3 | 47.7 | 59.8 | 8.0 | 451.00 | 82.30 | 18.96 |
| SY 240-1 F | 76.20 | 47.63 | 47.63 | 23.78 | 95.5 | 104.0 | 47.8 | 56.2 | 70.3 | 9.5 | 677.00 | 112.80 | 26.47 |
100 F から 160 Fの継手リンクは全て割りピン式です。200 F と 240 Fの継手リンクは通しSピン式です。オフセットリンクはありません。
